Rockwell Automation Publication 20C-PM001F-EN-P - March 2012 39
Programming and Parameters Chapter 2
UTILITY
Diagnostics
212 [Drive Alarm 2]
Alarm conditions that currently exist in the drive.
Notes: Bits 14 and 15 were added for firmware revision 2.001.
Bits 8, 9 and 11 were changed to “Reserved” for firmware
revision 3.001. Bit 0 was changed from “DigIn Test” to “DigIn
CflctA” and bit 11 “UserSetCflct” was added for firmware
revision 4.001. Bit 8 “Fan Cooling” was added for firmware
revision 6.001.
1 = Condition True
0 = Condition False
Read Only 211
213 [Speed Ref Source]
Displays the source of the speed reference to the
drive.
Default:
Options: 0
1
2
3…8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
Read Only
“PI Output”
“Analog In 1”
“Analog In 2”
“Reserved”
“MOP Level”
“Jog Speed 1”
“Preset Spd1”
“Preset Spd2”
“Preset Spd3”
“Preset Spd4”
“Preset Spd5”
“Preset Spd6”
“Preset Spd7”
“DPI Port 1”
“DPI Port 2”
“DPI Port 3”
“DPI Port 4”
“DPI Port 5”
““Reserved”
“Auto Tune”
“Jog Speed 2”
090
093
096
101
214 [Start Inhibits]
Displays the inputs currently preventing the drive from
starting.
Notes: Bit 15 was added for firmware revision 2.001. Bit 14 was
changed to “Reserved” for firmware revision 3.001.
1 = Inhibit True
0 = Inhibit False
Read Only
File
Group
No.
Parameter Name & Description Values
Related
Name
HDW OverTemp
PTC Cflct
TB Ref Cflct
Sleep Config
UserSetCflct
SpdRef Cflct
Reserved
Fan Cooling
VHz NegSlope
MaxFrq Cflct
NP Hz Cflct
MtrTyp Cflct
Bipolr Cflct
DigIn CflctC
DigIn CflctB
DigIn CflctA
Default000000x000000000
Bit 1514131211109876543210
Name
Gate Disable
Reserved
DPI Port 5
DPI Port 4
DPI Port 3
DPI Port 2
DPI Port 1
Digital In
Reserved
Startup Actv
Params Reset
Stop Assertd
DC Bus Pchrg
Enable
Tyep 2 Alarm
Fault
Default0x000000x0000000
Bit 1514131211109876543210
