Allen-Bradley PowerFlex 700H Programming Manual

40 Rockwell Automation Publication 20C-PM001F-EN-P - March 2012
Chapter 2 Programming and Parameters
UTILITY
Diagnostics
215 [Last Stop Source]
Displays the source that initiated the most recent
stop sequence. It will be cleared (set to 0) during
the next start sequence.
Default:
Options: 0
1
2
3
4
5
6
7
8
9
10
11
12
13
Read Only
“Pwr Removed”
“DPI Port 1”
“DPI Port 2”
“DPI Port 3”
“DPI Port 4”
“DPI Port 5”
“Reserved”
“Digital In”
“Fault”
“Not Enabled”
“Sleep”
“J og”
“Au to tu ne ”
“Precharge”
361
362
363
364
365
366
216 [Dig In Status]
Status of the digital inputs.
1 = Input Present
0 = Input Not Present
Read Only 361
thru
366
217 [Dig Out Status]
Status of the digital outputs.
1 = Output Energized
0 = Output De-energized
Read Only 380
384
388
thru
380
384
388
218 [Drive Temp]
Present operating temperature of the drive power
section.
Default:
Min/Max:
Units:
Read Only
0.0/100.0%
0.1%
220 [Motor OL Count]
Accumulated percentage of motor overload.
Continuously operating the motor over 100% of
the motor overload setting will increase this value
to 100% and cause a drive fault.
Default:
Min/Max:
Units:
Read Only
0.0/100.0%
0.1%
047
048
224 [Fault Frequency]
Captures and displays the output speed of the
drive at the time of the last fault.
Default:
Min/Max:
Units:
Read Only
0.0/+[Maximum Freq]
0.1 Hz
079
225
thru
230
225 [Fault Amps]
Captures and displays motor amps at the time of
the last fault.
Default:
Min/Max:
Units:
Read Only
0.0/[Rated Amps] × 2
0.1 Amps
224
thru
230
226 [Fault Bus Volts]
Captures and displays the DC bus voltage of the
drive at the time of the last fault.
Default:
Min/Max:
Units:
Read Only
0.0/Max Bus Volts
0.1 VDC
224
thru
230
File Group No.
Parameter Name & Description Values
Related
Name Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Digital In6 Digital In5 Digital In4 Digital In3 Digital In2 Digital In1
Defaultxxxxxxxxxx000000
Bit 1514131211109876543210
Name Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Digital Out3 Digital Out2 Digital Out1
Defaultxxxxxxxxxxxxx000
Bit 1514131211109876543210
