3-24 Access Procedures
Installation
1. On Power Structure 1, replace the Adapter Board and install the cable
ties, which secure it to the circuit boards on the Output Power Modules.
2. Plug the old stacker connectors into the new Gate Driver Board so the
pins do not protrude through the connectors on the back of the board.
3. Align the Gate Driver Board so that its connectors align with the mating
connectors on the Adapter Board.
4. While supporting the Adapter Board from behind, press the Gate Driver
Board onto it.
5. Verify the proper alignment of the mounting with a mirror. Verify that
none of the pins in the stacker connectors have missed the mating
connectors.
6. Install the brackets, and install and tighten the mounting screws.
7. Connect all of the cables on the new Gate Driver Board.
8. Repeat steps 1 - 7 to install the Gate Driver and Adapter Boards on
Power Structure 2.
