A-2 Service Tools and Equipment
Service tools
This list of basic service tools which will cover needs of tools for repair and
maintenance measurements.
Item Description Details
1 Oscilloscope Portable, digitizing, dual channel scope, with isolation
2 Current clamp 1000A(ac, rms), signal output
3 Soldering station Soldering / de soldering
4 Adjustable power supply 0...1300Vdc, 1A, adjustable current limit. Efore LPS
750-HV or equivalent.
5 Adjustable power supply 0...690Vac (+10%), 10A, three phase, galvanic
isolation
6 Multi meter Digital multi meter, capable of ac and dc voltage,
continuity, resistance, capacitance measurements,
and forward diode bias tests. Fluke model 87 III or
equivalent.
7 Insulation tester 1000Vdc
8 Torque wrench 1...12Nm
9 Torque wrench 6...50Nm
10 box wrench 7mm, 8mm, 10mm, 13mm, 17mm, 19mm, 22mm
11 socket extension 230mm
12 Wrench 7mm, 8mm, 10mm, 13mm, 17mm, 19mm, 22mm
13 Wire cutter
14 Nose pliers
15 Crimping tools For cable terminals 1,5...240
16 Angle wrench
17 Screw driver
18 *Flat nose 7*2(mm)
19 *POZIDRIV 1, 2, 3
20 *Phillips 1, 2, 3
21 *Torx 25
22 Hexagonal wrench 4, 5, 6
23 ESD-protected place of work Working surface, Floor covering, seat and ground
connections
24 ESD-protective clothing Wrist wrap, shoes, overall clothing (coat)
25 Power supply (service) Capacity of three phase service 400/500/690Vac, 30A
26 20-MAINSTND maintenance stand Maintenance stand for removing power structure from
drive cabinet
27 Fiber-optic repair kit Agilent HFBR-4593 Polishing Kit, consisting of a
Polishing Fixture, 600 grit abrasive paper and 3 mm
pink lapping film (3M Company, OC3-14).
For Agilent HFBR-4532 latching connectors and
HFBR-RL cable. Refer to Agilent publications
5988-9777EN and 5988-3625EN.
