Drive Port 0 Parameters Chapter 3
File Group
No. Display Name
Full Name
Description
Values
Read-Write Data Type
COMMUNICATION
ODK Datalinks
1700…1731 UserData Int 00…31
User Data Integer 00…31
Available for storage of a 32-bit integer value by the user.
Default:
Min/Max:
0
-2147483647 / 2147483647
RW 32-bit
Integer
1800…1831 UserData Real 00…31
User Data Real 00…31
Available for storage of a real value by the user.
Default:
Min/Max:
0.0000
-2147483647 / 2147483647
RW Float
1900
1904
1908
1912
1916
1920
1924
1928
ScaleBlk Sel 00
ScaleBlk Sel 01
ScaleBlk Sel 02
ScaleBlk Sel 03
ScaleBlk Sel 04
ScaleBlk Sel 05
ScaleBlk Sel 06
ScaleBlk Sel 07
Scale Block Select n
Selects the source value to be scaled.
Default:
Min/Max:
Disabled
0 / 159999
RW 32-bit
Integer
1901
1905
1909
1913
1917
1921
1925
1929
ScaleBlk Scal 00
ScaleBlk Scal 01
ScaleBlk Scal 02
ScaleBlk Scal 03
ScaleBlk Scal 04
ScaleBlk Scal 05
ScaleBlk Scal 06
ScaleBlk Scal 07
Scale Block Scale n
Scales (multiplier) the selected parameter value.
Default:
Min/Max:
1.0000
-2147483647 / 2147483647
RW Float
1902
1906
1910
1914
1918
1922
1926
1930
ScaleBlk Int 00
ScaleBlk Int 01
ScaleBlk Int 02
ScaleBlk Int 03
ScaleBlk Int 04
ScaleBlk Int 05
ScaleBlk Int 06
ScaleBlk Int 07
Scale Block Integer n
Displays the scaling result as a 32-bit integer value.
Default:
Min/Max:
0
-2147483647 / 2147483647
RO 32-bit
Integer
1903
1907
1911
1915
1919
1923
1927
1931
ScaleBlk Real 00
ScaleBlk Real 01
ScaleBlk Real 02
ScaleBlk Real 03
ScaleBlk Real 04
ScaleBlk Real 05
ScaleBlk Real 06
ScaleBlk Real 07
Scale Block Real n
Displays the scaling result as a real value.
Default:
Min/Max:
0.0000
-2147483647 / 2147483647
RO Float
