Rockwell Automation Publication 750-PM001N-EN-P - February 2017 527
Integrated Motion on EtherNet/IP Application Appendix F
Faults
Tab le shows the correlation between PowerFlex 755 faults and the respective
faults that are returned to the Logix controller and RSLogix 5000 software. The
returned fault numbers and text are common with the Kinetix 6500.
Note: A fault code/message that is displayed on a HIM does not match what is
returned to the Logix controller and potentially displayed on an HMI or viewed
in RSLogix 5000 software.
Table 39 - PowerFlex 755 Drive Fault Numeric Order
PowerFlex 755 Drive Integrated Motion on EtherNet/IP
Event No. Fault Text Code Subcode Fault Text
0No Entry 00No Faults
2 Auxiliary Input 63 0 External Exception Input
3Power Loss 370Bus Power Loss
4 UnderVoltage 34 0 Bus Undervoltage User Limit
5 OverVoltage 35 0 Bus Overvoltage Factory Limit
7 Motor Overload 7 0 Motor Thermal Overload Factory
Limit
8 Heatsink OvrTemp 11 1 Inverter Overtemperature Factory
Limit
9 Trnsistr OvrTemp 11 2 Inverter Overtemperature Factory
Limit
12 HW OverCurrent 10 1 Inverter Overcurrent
13 Ground Fault 16 0 Converter Ground Current Factory
Limit
14 Ground Warning 17 0 Converter Ground Current User Limit
15 Load Loss 57 0 Undertorque Limit
17 Input Phase Loss 23 0 Converter AC Single Phase Loss
20 TorqPrv Spd Band 18 1 Torque Prove Failure
21Output PhaseLoss 6321Product Specific
24 Decel Inhibit 19 0 Decel Override
25 OverSpeed Limit 4 0 Motor Overspeed User Limit
26 Brake Slipped 18 2 Torque Prove Failure
33 AuRsts Exhausted 63 33 Product Specific
36 SW OverCurrent 10 2 Inverter Overcurrent
38 Phase U to Gnd 24 1 Converter AC Phase Short
39 Phase V to Gnd 24 2 Converter AC Phase Short
40 Phase W to Gnd 24 3 Converter AC Phase Short
41 Phase UV Short 24 4 Converter AC Phase Short
42 Phase VW Short 24 5 Converter AC Phase Short
43 Phase WU Short 24 6 Converter AC Phase Short
44 Phase UNegToGnd 24 7 Converter AC Phase Short
45 Phase VNegToGnd 24 8 Converter AC Phase Short
46 Phase WNegToGnd 24 9 Converter AC Phase Short
48System Defaulted 6333Product Specific
49 Drive Powerup 1 0 Module Reset
55 Ctrl Bd Overtemp 10 0 Control Module Overtemperature
Factory Limit
61 Shear Pin 1 56 0 Overtorque Limit
