528 Rockwell Automation Publication 750-PM001N-EN-P - February 2017
Appendix F Integrated Motion on EtherNet/IP Application
64 Drive OverLoad 13 0 Converter Pre-charge Overload User
Limit
71Port 1 Adapter 6371Product Specific
72Port 2 Adapter 6372Product Specific
73Port 3 Adapter 6373Product Specific
74Port 4 Adapter 6374Product Specific
75Port 5 Adapter 6375Product Specific
76Port 6 Adapter 6376Product Specific
77 IR Volts Range 21 1 Motor Test Failure
78 FluxAmpsRef Rang 21 2 Motor Test Failure
79 Excessive Load 21 3 Motor Test Failure
80 AutoTune Aborted 21 4 Motor Test Failure
81 Port 1 DPI Loss 63 81 Product Specific
82 Port 2 DPI Loss 63 82 Product Specific
83 Port 3 DPI Loss 63 83 Product Specific
84 Port 4 DPI Loss 63 84 Product Specific
85 Port 5 DPI Loss 63 85 Product Specific
86 Port 6 DPI Loss 63 86 Product Specific
87 IXo VoltageRange 21 5 Motor Test Failure
91 Pri VelFdbk Loss 45 255 Feedback Data Loss Factory Limit
93Hw Enable Check 6393Product Specific
94 Alt VelFdbk Loss 45 255 Feedback Data Loss Factory Limit
95 Aux VelFdbk Loss 45 255 Feedback Data Loss Factory Limit
96 PositionFdbkLoss 45 255 Feedback Data Loss Factory Limit
100 Parameter Chksum 3 0 Nonvolatile Memory Checksum Fault
104 Pwr Brd Checksum 15 1 Power Board
106 Incompat MCB-PB 15 3 Power Board
107 Replaced MCB-PB 22 1 Hardware Configuration
111 PwrBd Invalid ID 15 2 Power Board
112 PwrBd App MinVer 15 4 Power Board
113 Tracking DataErr 22 2 Hardware Configuration
117 PwrDn Data Chksm 17 16 Option Storage Checksum
124 App ID Changed 23 1 Firmware Change
125 Using Backup App 23 2 Firmware Change
134 Start On PowerUp 63 134 Product Specific
137 Ext Prchrg Err 23 2 Converter Pre-Charge Failure
138 Precharge Open 23 3 Converter Pre-Charge Failure
141 Autn Enc Angle 21 6 Motor Test Failure
142 Autn Spd Rstrct 21 7 Motor Test Failure
143 Autotune CurReg 21 8 Motor Test Failure
144 Autotune Inertia 21 9 Motor Test Failure
145 Autotune Travel 21 10 Motor Test Failure
169 PWM Freq Reduced 16 0 PWM Frequency Reduced
Table 39 - PowerFlex 755 Drive Fault Numeric Order (Continued)
PowerFlex 755 Drive Integrated Motion on EtherNet/IP
Event No. Fault Text Code Subcode Fault Text
