Rockwell Automation Publication 750-PM001N-EN-P - February 2017 7
Preface
The purpose of this manual is to provide you with the basic information
required to install, start-up, and troubleshoot PowerFlex® 750-Series Adjustable
Frequency AC Drives. This manual is intended for qualified personnel. You
must be able to program and operate Adjustable Frequency AC Drive devices.
In addition, you must have an understanding of the parameter settings and
functions. The PowerFlex 750-Series AC Drives Quick Start, publication 750-
QS001, is designed to provide only basic start-up information.
Summary of Changes
This manual contains new and updated information as indicated in the
following table.
Product Certification
Product Certifications and Declarations of Conformity are available on the
Internet at:
http://www.rockwellautomation.com/global/certification/overview.page
.
Manual Conventions
• In this manual we refer to PowerFlex 750-Series Adjustable Frequency
AC Drives as: drive, PowerFlex 750, PowerFlex 750 drive, or PowerFlex
750 AC drive.
• Specific drives within the PowerFlex 750-Series can be referred to as:
– PowerFlex 753, PowerFlex 753 drive, or PowerFlex 753 AC drive
– PowerFlex 755, PowerFlex 755 drive, or PowerFlex 755 AC drive
• To help differentiate parameter names and LCD display text from other
text, the following conventions are used.
– Parameter names will appear in [brackets] after the parameter
number.
For example: parameter 308 [Direction Mode].
– Display text appears in “quotes.” For example: “Enabled.”
Topic Page
Added parameter 41, [Common Mode Type]. 52
Updated the default value of bit 6 “VCmdPhShftEn” in parameter 80 {PM Cfg]. 58
Added parameter 365 [FS Brk Lvl], parameter 366 [FS Brk Time], and parameter 367 [FS ZSpd Thresh]. 89
Updated the Read-Write value of parameters 759…761 to RO. 135
Updated the description of bit 4 “Accelerating” in parameter 935 [Drive Status 1]. 154
Updated the description of bit 3 “Preload” in parameter 1100 [Trq Prove Cfg]. 174
Updated the information associated with event numbers 10137…10338 in Table 12. 324
Updated the parameter number associated with parameter [FB1 SSI Cfg] in Table 14. 525
