Rockwell Automation Publication 750-PM001N-EN-P - February 2017 159
Drive Port 0 Parameters Chapter 3
DIAGNOSTICS
Status
940 Drive OL Count
Drive Overload Count
Indicates power unit overload (IT) in percentage. When the value reaches 100%, the
power unit overload fault occurs.
Units:
Default:
Min/Max:
%
0.00
0.00 / 200.00
RO Real
941 IGBT Temp Pct
Insulated-Gate Bipolar Transistor Temperature Percent
Indicates IGBT junction temperature in percentage of the maximum junction
temperature. The value of this parameter is calculated.
Units:
Default:
Min/Max:
%
0.00
–/+200.00
RO Real
942 IGBT Temp C
Insulated-Gate Bipolar Transistor Temperature Celsius
Indicates IGBT junction temperature in centigrade. The value of this parameter is
calculated.
Units:
Default:
Min/Max:
DegC
0.00
–/+200.00
RO Real
943 Drive Temp Pct
Drive Temperature Percent
Indicates operating temperature of the drive power section (heat-sink) in percentage of
the maximum heat-sink temperature. The value of this parameter is measured.
Units:
Default:
Min/Max:
%
0.00
–/+200.00
RO Real
944 Drive Temp C
Drive Temperature Celsius
Present operating temperature of the drive power section. The value of this parameter is
measured.
Units:
Default:
Min/Max:
DegC
0.00
–/+200.00
RO Real
File
Group
No. Display Name
Full Name
Description
Values
Read-Write
Data Type
