Allen-Bradley PowerFlex 750 Series Programming Manual

Rockwell Automation Publication 750-PM001N-EN-P - February 2017 201
Drive Port 0 Parameters Chapter 3
APPLICATIONS
Roll Position
1507 RP Rvls Input
Roll Position Indicator Revolutions Input
Sets revolution of the input encoder. This parameter must be coordinated with the
revolution of the output encoder P1508 [RP Rvls Output] to resolve the gear ratio
between input revolutions and output (virtual) revolutions. The ratio of input to output
revolutions can always be resolved into integer values and should be reduce to their
lowest common factor.
Default:
Min/Max:
1
–/+1000000
RW 32-bit
Integer
1508 RP Rvls Output
Roll Position Indicator Revolutions Output
Sets revolution of the output encoder. This parameter must be coordinated with the
revolution of the input encoder P1507 [RP Rvls Input] to resolve the gear ratio between
input revolutions and output (virtual) revolutions. The ratio of input to output
revolutions can always be resolved into integer values and should be reduce to their
lowest common factor.
Default:
Min/Max:
1
1 / 4294967295
RW 32-bit
Integer
1509 RP Unwind
Roll Position Indicator Unwind Count
Sets the number of counts per roll revolution. P1511 [RP Psn Output] rolls over at this
count minus 1.
Default:
Min/Max:
4194304
1024 / 536870912
RW 32-bit
Integer
1510 RP Unit Scale
Roll Position Indicator Unit Scale
Provides the multiplier to P1512 [RP Unit Out], which is a floating point output of P1511
[RP Psn Output].
Default:
Min/Max:
1.00000
–/+220000000.00000
RW Real
1511 RP Psn Output
Roll Position Indicator Position Output
Output of roll position, which has a span limited by P1509 [RP Unwind].
Default:
Min/Max:
0
0 / 4294967295
RO 32-bit
Integer
1512 RP Unit Out
Roll Position Indicator Unit Output
Floating point output that results from multiplying P1511 [RP Psn Output] by P1510 [RP
Unit Scale].
Default:
Min/Max:
0.00
–/+220000000.00
RO Real
File Group
No. Display Name
Full Name
Description
Values
Read-Write Data Type
755
755
755
755
755
755
File Group
No. Display Name
Full Name
Description
Values
Read-Write Data Type
APPLICATIONS
Torque Boost
1515 PsnTrqBst Ctrl
Position Oriented Torque Boost Control
RW 16-bit
Integer
Configuration for the Position Oriented Torque Boost function.
Bit 0 “Boost Enable” – Enables the Position Oriented Torque Boost function.
755
Options
Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Boost Enable
Default0000000000000000
Bit 1514131211109876543210
0 = Disabled
1 = Enabled
