Chapter 4 Port 10 and Port 11 Parameters
CONVERTER N
Metering
125
225
325
C1 L12 Line Volt
C2 L12 Line Volt
C3 L12 Line Volt
Converter n Line 1 to Line 2 Line Voltage
The phase-to-phase RMS line voltage between L1 and L2 for converter n.
Units:
Default:
Min/Max:
V AC
0.0
0.0 / 850.0
RO Real
126
226
326
C1 L23 Line Volt
C2 L23 Line Volt
C3 L23 Line Volt
Converter n Line 2 to Line 3 Line Voltage
The phase-to-phase RMS line voltage between L2 and L3 for converter n.
Units:
Default:
Min/Max:
V AC
0.0
0.0 / 850.0
RO Real
127
227
327
C1 L31 Line Volt
C2 L31 Line Volt
C3 L31 Line Volt
Converter n Line 3 to Line 1 Line Voltage
The phase-to-phase RMS line voltage between L3 and L1 for converter n.
Units:
Default:
Min/Max:
V AC
0.0
0.0 / 850.0
RO Real
File Group
No. Display Name
Full Name
Description
Values
Read-Write Data Type
755 (8+)
755 (8+)
755 (8+)
755 (8+)
755 (8+)
755 (8+)
755 (8+)
755 (8+)
755 (8+)
File Group
No. Display Name
Full Name
Description
Values
Read-Write Data Type
CONVERTER N
Predictive Main
137
237
337
C1 PredMainReset
C2 PredMainReset
C3 PredMainReset
Converter n Predictive Maintenance Reset
Allows a reset of the elapsed run time to zero for the cabinet fan for converter n. After
the time has been reset, the value of this parameter returns to 0 “Ready.”
Default:
Options:
0 = “Ready”
0 = “Ready”
1 = “Cb Fan Life”
RW Real
138
238
338
C1 CbFanElpsdLif
C2 CbFanElpsdLif
C3 CbFanElpsdLif
Converter n Cabinet Fan Elapsed Life
The amount of time the cabinet fan for converter n has been running. This value can be
reset using [Cn PredMainReset].
Units:
Default:
Min/Max:
Hrs
0.000
0.000 / 2200000.000
RO Real
755 (8+)
755 (8+)
755 (8+)
755 (8+)
755 (8+)
755 (8+)
File Group
No. Display Name
Full Name
Description
Values
Read-Write Data Type
CONVERTER N
Testpoints
140
142
240
242
340
342
C1 Testpt Sel 1
C1 Testpt Sel 2
C2 Testpt Sel 1
C2 Testpt Sel 2
C3 Testpt Sel 1
C3 Testpt Sel 2
Converter n Testpoint Selection 1, 2
Selects a source for [Cn Testpt Val n]. Used by the factory, typically for diagnostic
purposes.
Default:
Min/Max:
0
0 / 65535
RW 32-bit
Integer
141
143
241
243
341
343
C1 Testpt Val 1
C1 Testpt Val 2
C2 Testpt Val 1
C2 Testpt Val 2
C3 Testpt Val 1
C3 Testpt Val 2
Converter n Testpoint Value 1, 2
Displays the data selected by [Cn Testpt Sel n].
Default:
Min/Max:
0.000000
–/+220.000000
RO Real
755 (8+)
755 (8+)
755 (8+)
755 (8+)
755 (8+)
755 (8+)
755 (8+)
755 (8+)
755 (8+)
755 (8+)
755 (8+)
755 (8+)
