Allen-Bradley PowerFlex 750 Series Programming Manual

Rockwell Automation Publication 750-PM001N-EN-P - February 2017 247
Embedded Feature and Option Module Parameters Chapter 5
File Group
No. Display Name
Full Name
Description
Values
Read-Write Data Type
11-Series I/O
Analog Inputs
45 Anlg In Type
Analog Input Type
RO 16-bit
Integer
Status of the analog input mode set by the option jumpers.
46 Anlg In Sqrt
Analog Input Square Root
RW 16-bit
Integer
Enables/disables the square root function for each input.
47 Anlg In Loss Sts
Analog Input Loss Status
RO 16-bit
Integer
Status of the analog input loss.
Bit 0 “Loss” – Indicates loss of input.
Bit 1 “Loss0” – Indicates loss of input.
Options
Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Analog 0
Default0000000000000000
Bit 1514131211109876543210
0 = Voltage Mode
1 = Current Mode
Options
Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Analog 0
Default0000000000000000
Bit 1514131211109876543210
0 = Square Root Disabled
1 = Square Root Enabled
Options
Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Loss0 Loss
Default0000000000000000
Bit 1514131211109876543210
0 = No Loss
1 = Loss Detected
