Allen-Bradley PowerFlex 750 Series Programming Manual

270 Rockwell Automation Publication 750-PM001N-EN-P - February 2017
Chapter 5 Embedded Feature and Option Module Parameters
File Group
No. Display Name
Full Name
Description
Values
Read-Write Data Type
Dual Incremental Encoder
Homing Cfg
20 Homing Cfg
Homing Configure
RW 16-bit
Integer
Configures options for the homing function. Common to both encoders.
Bit 0 “Inv Home In” – Inverts the home input signal.
Options
Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Inv Home In
Default0000000000000000
Bit 1514131211109876543210
0 = Not Inverted
1 = Inverted
File Group
No. Display Name
Full Name
Description
Values
Read-Write Data Type
Dual Incremental Encoder
Module Status
21 Module Sts
Module Status
RO 16-bit
Integer
Encoder module status information. Common to both encoders.
Bit 0 “Safety Mode” – Indicates that the dip switch on the dual encoder module is configured to place its feedback signals on the SI backplane for use by the Safe
Speed Monitor module. If multiple dual encoder modules are present, only one dual encoder can be configured for Safety Mode. 0 = Safety Mode Off. 1 = Safety
Mode On.
Bit 1 “SafetyVoltHi” – Indicates the status (configured by a jumper on the module) of the safety feedback voltage mode. 0 = 5V safety feedback mode, 1 = 12V
safety feedback mode.
Options
Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved SafetyVoltHi Safety Mode
Default0000000000000000
Bit 1514131211109876543210
0 = Cleared
1 = Set
