Chapter 2 Parameter Organization
Expert Parameter View (Port 0)
Parameter 301 [Access Level] set to option 2 “Expert.”
File Group Parameters
Monitor Metering Output Frequency 1
Commanded SpdRef 2
Mtr Vel Fdbk 3
Commanded Trq 4
Torque Cur Fdbk 5
Flux Cur Fdbk 6
Output Current 7
Output Voltage 8
Output Power 9
Output Powr Fctr 10
DC Bus Volts 11
DC Bus Memory 12
Elapsed MWH 13
Elapsed kWH 14
Elapsed Run Time 15
Elpsd Mtr MWHrs 16
Elpsd Rgn MWHrs 17
Elpsd Mtr kWHrs 18
Elpsd Rgn kWHrs 19
Drive Data Rated Volts 20 Rated Amps 21 Rated kW 22
Motor Control Motor Data Motor NP Volts 25
Motor NP Amps 26
Motor NP Hertz 27
Motor NP RPM 28
Mtr NP Pwr Units 29
Motor NP Power 30
Motor Poles 31
Mtr Ctrl Options Motor Ctrl Mode 35
Maximum Voltage 36
Maximum Freq 37
PWM Frequency 38
Mtr Options Cfg 40
Common Mode Type 41
Bus Utilization 42
Flux Up Enable 43
Flux Up Time 44
Flux Down Ki 45
Flux Down Kp 46
Econ At Ref Ki 47
Econ AccDec Ki 48
Econ AccDec Kp 49
Stability Filter 50
Stab Volt Gain 51
Stab Angle Gain 52
IPM V FB HP Filt 1648
IPM SpdEst Filt 1649
IPM SpdEst Kp 1650
IPM SpdEst Ki 1651
IPM SpdEst KiAdj 1652
IPM Tran PWM 1653
IPMTran PWM Hyst 1654
IPM Tran Mode 1655
IPM TranMod Hyst 1656
IPM Tran Filt Lo 1657
IPM Tran Filt Hi 1658
IPM Tran Angle 1659
IPM Stc OfsTst K 1660
IPM Lq Cmd BW 1661
Parameters 1648…1661 used
by drive frames 1…7 only.
Volts per Hertz Start Acc Boost 60
Run Boost 61
Break Voltage 62
Break Frequency 63
SVC Boost Filter 64
VHz Curve 65
Autotune Autotune 70
Autotune Torque 71
IR Voltage Drop 73
Ixo Voltage Drop 74
Flux Current Ref 75
Total Inertia 76
Inertia Test Lmt 77
Encdrlss AngComp 78
Encdrlss VltComp 79
PM Cfg 80
PM PriEnc Offset 81
PM AltEnc Offset 82
PM OfstTst Cur 83
PM OfstTst CRamp 84
PM OfstTst FRamp 85
PM CEMF Voltage 86
PM IR Voltage 87
PM IXq Voltage
755
88
PM IXd Voltage
755
89
PM Vqs Reg Kp 91
PM Vqs Reg Ki 92
PM Dir Test Cur 93
PM IXqVoltage125 120
IPM_Lg_25_pct 1630
IPM_Lg_50_pct 1631
IPM_Lg_75_pct 1632
IPM_Lg_100_pct 1633
IPM_Lg_125_pct 1634
IPM_Ld_0_pct 1635
IPM_Ld_100_pct 1636
IPM PriOffstComp 1646
IPM AltOffstComp 1647
Vector Regulator VCL Cur Reg BW 95
VCL Cur Reg Kp 96
VCL Cur Reg Ki 97
VEncdls FReg Kp 98
VEncdls FReg Ki 99
Slip Reg Enable 100
Slip Reg Ki 101
Slip Reg Kp 102
Flux Reg Enable 103
Flux Reg Ki 104
Flux Reg Kp 105
Trq Adapt Speed 106
Trq Adapt En 107
Phase Delay Comp 108
Trq Comp Mode 109
Trq Comp Mtring 110
Trq Comp Regen 111
Slip Adapt Iqs 112
SFAdapt SlewLmt 113
SFAdapt SlewRate 114
SFAdapt CnvrgLvl 115
SFAdapt CnvrgLmt 116
IPM Bus Prot
755
1629
IPMVqFFwdCemf
755
1637
IPMVqFFwdLdIdWe
755
1638
IPMVdFFwdLqIqWe
755
1639
IPM Max Cur
755
1640
IPM Max Spd
755
1641
IPM TrqTrim Kp
755
1642
IPM TrqTrim Ki
755
1643
IPM TrqTrim HLim
755
1644
IPM TrqTrim LLim
755
1645
Monitor
Motor Control
To Next Page
