Rockwell Automation Publication 750-PM001N-EN-P - February 2017 321
Troubleshooting Chapter 6
Table 11 - Drive Fault and Alarm Cross Reference By Name
Fault/Alarm Text Number Fault/Alarm Text Number
Adj Vltg Ref 171 Fwd Spd Lim Cfg 192
Alt VelFdbk Loss 94 Ground Fault 13
AltSpdReg DL Err 202 Ground Warning 14
Analog In Loss 29 Heatsink OvrTemp 8
Anlg Cal Chksum 108 HeatSinkUnderTmp 168
App ID Changed 124 Home Not Set 179
AuRsts Exhausted 33 Homing Active 178
Autn Enc Angle 141 HS Temp Imbal U 327
Autn Spd Rstrct 142 HS Temp Imbal V 328
Auto Tach Switch 97 HS Temp Imbal W 329
AutoTune Aborted 80 HSFan Life 291
Autotune CurReg 143 Hw Enable Check 93
Autotune Inertia 144 HW Enbl Jmpr Out 210
Autotune Travel 145 HW OverCurrent 12
Aux VelFdbk Loss 95 I1 Comm Loss 331
Auxiliary Input 2 I2 Comm Loss 332
Bipolar Conflict 155 In Cur Share L1 351
Brake Slipped 26 In Cur Share L2 352
C1 Comm Loss 341 In Cur Share L3 353
C2 Comm Loss 342 In Vlt Imbal L12 357
CBP Num Mismatch 364 In Vlt Imbal L23 358
CBP/Inv Mismatch 363 In Vlt Imbal L31 359
Clr Fault Queue 51 Incompat MCB-PB 106
Cnv Num Mismatch 366 InFan Life 292
Cnv/Inv Mismatch 362 Input Phase Loss 17
Comm Loss Net 280 Invalid Code 59
Ctrl Bd Overtemp 55 IPM OverCurrent 35
CurLimit Reduced 170 IPMSpdEstErr 195
DC Bus Mismatch 324 IR Volts Range 77
Decel Inhibit 24 Ivld Pwr Bd Data 110
DigIn Cfg B 157 IXo VoltageRange 87
DigIn Cfg C 158 Load Loss 15
DLX Checksum 282 MachBrng Life 295
DPI TransportErr 205 MachBrng Lube 296
Drive OverLoad 64 Module Defaulted 58
Drive Powerup 49 Motor Overload 7
DynBrake OvrTemp 10 Motor PTC Trip 18
Enet Checksum 281 MtrBrng Life 293
Excess Psn Err 315 MtrBrng Lube 294
Excessive Load 79 N-1 Operation 322
Ext Prechrg Err 137 N-1 See Manual 360
FluxAmpsRef Rang 78 Net IO Timeout 14037
Freq Conflict 185 No Stop Source 152
Fwd End Limit 181 NVS Not Blank 102
