340 Rockwell Automation Publication 750-PM001N-EN-P - February 2017
Chapter 6 Troubleshooting
4. Energize the drive.
With the addition of a drive assembly, port verification errors indicate the
number of installed drive assemblies. For example, a frame 9 would
indicate “Two Inverters” and “Two Converters.”
5. On the HIM press FIX to acknowledge the error then Enter to confirm.
An F361 “Rerate See Manual” fault is indicated.
6. Verify the new rating shown in Port 10, P21 [Effctv I Rating].
Set Port 10, P20 [Recfg Acknowledg] to 1 “Acknowledge” to accept the
reconfiguration.
7. To clear the fault, press the Stop key on the HIM.
P20 [Recfg Acknowledg] automatically returns to 0 “Ready.”
8. Use the HIM download function, DriveExecutive download function, or
DriveExplorer download function to download the parameter settings
saved in Step1.
9. Run the drive at the full rating and full power limits.
Drive parameters are set to factory defaults when reconfiguration is
acknowledged. If a condition exists that does not allow the drive
parameters to be set to factory defaults, setting P20 to 1
“Acknowledge” is not accepted. Such conditions include the drive is
running, DeviceLogix is running, or the drive is communicating with a
PLC.
Do not use the Compare Screen Copy function in DriveExecutive or the
Error Check Download function in DriveExplorer to perform this step.
