Rockwell Automation Publication 750-PM001N-EN-P - February 2017 45
Parameter Organization Chapter 2
Universal Feedback Module
Parameter descriptions begin on page 271.
File Group Parameters
Universal
Feedback Host
Groups
Module Module Sts 1
Module Err Reset 2
Feedback 0 FB0 Position 5
FB0 Device Sel 6
FB0 Identify 7
FB0 Cfg 8
FB0 Loss Cfg 9
FB0 Sts 10
FB0 IncAndSC PPR 15
FB0 Inc Cfg 16
FB0 Inc Sts 17
FB0 SSI Cfg 20
FB0 SSI Resol 21
FB0 SSI Turns 22
FB0 Lin CPR 25
FB0 Lin Upd Rate 26
FB0 LinStahl Sts 27
Feedback 1 FB1 Position 35
FB1 Device Sel 36
FB1 Identify 37
FB1 Cfg 38
FB1 Loss Cfg 39
FB1 Sts 40
FB1 IncAndSC PPR 45
FB1 Inc Cfg 46
FB1 Inc Sts 47
FB1 SSI Cfg 50
FB1 SSI Resol 51
FB1 SSI Turns 52
FB1 Lin CPR 55
FB1 Lin Upd Rate 56
FB1 LinStahl Sts 57
Encoder Out Enc Out Sel 80
Enc Out Mode 81
Enc Out FD PPR 82 Enc Out Z Offset 83
Enc Out Z PPR 84
Registration Rgsn Arm 90
Rgsn In 0 Filter 91
Rgsn In 1 Filter 92
Rgsn HmIn Filter 93
Rgsn Sts 94
Rgsn Latch1 Cfg 100
Rgsn Latch2 Cfg 103
Rgsn Latch3 Cfg 106
Rgsn Latch4 Cfg 109
Rgsn Latch5 Cfg 112
Rgsn Latch6 Cfg 115
Rgsn Latch7 Cfg 118
Rgsn Latch8 Cfg 121
Rgsn Latch9 Cfg 124
Rgsn Latch10 Cfg 127
Rgsn Latch1 Psn 101
Rgsn Latch2 Psn 104
Rgsn Latch3 Psn 107
Rgsn Latch4 Psn 110
Rgsn Latch5 Psn 113
Rgsn Latch6 Psn 116
Rgsn Latch7 Psn 119
Rgsn Latch8 Psn 122
Rgsn Latch9 Psn 125
Rgsn Latch10 Psn 128
Rgsn Latch1 Time 102
Rgsn Latch2 Time 105
Rgsn Latch3 Time 108
Rgsn Latch4 Time 111
Rgsn Latch5 Time 114
Rgsn Latch6 Time 117
Rgsn Latch7 Time 120
Rgsn Latch8 Time 123
Rgsn Latch9 Time 126
Rgsn Latch10 Time 129
Universal Feedback
