PowerFlex 700 Dimensions 1-17
Figure 1.17 PowerFlex 700 Bottom View Dimensions – Frame 0
Dimensions are in millimeters and (inches)
Figure 1.18 PowerFlex 700 Bottom View Dimensions – Frame 1
Dimensions are in millimeters and (inches)
132.9
(5.23)
187.5
(7.38)
30.2
(1.19)
41.9 (1.65)
56.1 (2.21)
96.0 (3.78)
75.9 (2.99)
96.0 (3.78)
55.0 (2.17)
75.0 (2.95)
35.0 (1.38)
22.2 (0.87) Dia. – 4 Places
185.0
(7.28)
133.3
(5.25)
187.6
(7.39)
25.5
(1.00)
70.0 (2.76)
43.0 (1.69)
96.0 (3.78)
75.9 (2.99)
108.5 (4.27)
67.5 (2.66)
47.5 (1.87)
87.5 (3.44)
22.2 (0.87) Dia.
3 Places
28.6 (1.13) Dia.
185.1
(7.29)
