1-18 PowerFlex 700 Dimensions
Figure 1.19 PowerFlex 700 Bottom View Dimensions – Frame 2
Dimensions are in millimeters and (inches)
Figure 1.20 PowerFlex 700 Bottom View Dimensions – Frame 3
Dimensions are in millimeters and (inches)
39.3 (1.55)
57.2 (2.25)
72.7 (2.86)
106.0 (4.17)
139.4 (5.49)
177.4 (6.98)
167.5 (6.59)
156.9 (6.18)
150.9
(5.94)
184.8
(7.28)
157.5
(6.20)
112.1
(4.41)
22.4 (0.88) Dia.
2 Places
28.7 (1.13) Dia.
3 Places
66.0 (2.60)
94.7 (3.73)
105.3 (4.15)
97.0 (3.82)
137.2 (5.40)
187.0 (7.36)
22.7 (0.89)
29.0 (1.14)
127.7
(5.03)
151.1
(5.95)
160.1
(6.30)
165.1
(6.50)
184.5
(7.26)
22.2 (0.87) Dia.
28.6 (1.13) Dia.
2 Places
37.3 (1.47) Dia.
2 Places
