Allen-Bradley PowerFlex40 User Manual

3-2 Programming and Parameters
PowerFlex 40 Adjustable Frequency AC Drive FRN 1.xx - 7.xx User Manual
Publication 22B-UM001I-EN-E
Refer to page 3-45 for an alphabetical listing of parameters.
Parameter Organization
Advanced
Program Group
Display Group
Basic
Program Group
See page 3-9
Motor NP Volts P031
Motor NP Hertz P032
Motor OL Current P033
Minimum Freq P034
Maximum Freq P035
Start Source P036
Stop Mode P037
Speed Reference P038
Accel Time 1 P039
Decel Time 1 P040
Reset To Defalts P041
Voltage Class P042
Motor OL Ret P043
See page 3-3
Output Freq d001
Commanded Freq d002
Output Current d003
Output Voltage d004
DC Bus Voltage d005
Drive Status d006
Fault 1 Code d007
Fault 2 Code d008
Fault 3 Code d009
Process Display d010
Control Source d012
Contrl In Status d013
Dig In Status d014
Comm Status d015
Control SW Ver d016
Drive Type d017
Elapsed Run Time d018
Testpoint Data d019
Analog In 0-10V d020
Analog In 4-20mA d021
Output Power d022
Output Power Fctr d023
Drive Temp d024
Counter Status d025
Timer Status d026
Stp Logic Status d028
Torque Current d029
See page 3-14
Comm Loss Time A106
Comm Format A107
Language A108
Anlg Out Setpt A109
Anlg In 0-10V Lo A110
Anlg In 0-10V Hi A111
Anlg In4-20mA Lo A112
Anlg In4-20mA Hi A113
Slip Hertz @ FLA A114
Process Time Lo A115
Process Time Hi A116
Bus Reg Mode A117
Current Limit 2 A118
Skip Frequency A119
Skip Freq Band A120
Stall Fault Time A121
Analog In Loss A122
10V Bipolar Enbl A123
Var PWM Disable A124
Torque Perf Mode A125
Motor NP FLA A126
Autotune A127
IR Voltage Drop A128
Flux Current Ref A129
PID Trim Hi A130
PID Trim Lo A131
PID Ref Sel A132
PID Feedback Sel A133
PID Prop Gain A134
PID Integ Time A135
PID Diff Rate A136
PID Setpoint A137
PID Deadband A138
PID Preload A139
Stp Logic 0 A140
Stp Logic 1 A141
Stp Logic 2 A142
Stp Logic 3 A143
Stp Logic 4 A144
Stp Logic 5 A145
Stp Logic 6 A146
Stp Logic 7 A147
Stp Logic Time 0 A150
Stp Logic Time 1 A151
Stp Logic Time 2 A152
Stp Logic Time 3 A153
Stp Logic Time 4 A154
Stp Logic Time 5 A155
Stp Logic Time 6 A156
Stp Logic Time 7 A157
EM Brk Off Delay A160
EM Brk On Delay A161
MOP Reset Sel A162
DB Threshold A163
Comm Write Mode A164
Anlg Loss Delay A165
Analog In Filter A166
PID Invert Error A167
See page 3-14
Digital In1 Sel A051
Digital In2 Sel A052
Digital In3 Sel A053
Digital In4 Sel A054
Relay Out Sel A055
Relay Out Level A056
Opto Out1 Sel A058
Opto Out1 Level A059
Opto Out2 Sel A061
Opto Out2 Level A062
Opto Out Logic A064
Analog Out Sel A065
Analog Out High A066
Accel Time 2 A067
Decel Time 2 A068
Internal Freq A069
Preset Freq 0 A070
Preset Freq 1 A071
Preset Freq 2 A072
Preset Freq 3 A073
Preset Freq 4 A074
Preset Freq 5 A075
Preset Freq 6 A076
Preset Freq 7 A077
Jog Frequency A078
Jog Accel/Decel A079
DC Brake Time A080
DC Brake Level A081
DB Resistor Sel A082
S Curve % A083
Boost Select A084
Start Boost A085
Break Voltage A086
Break Frequency A087
Maximum Voltage A088
Current Limit 1 A089
Motor OL Select A090
PWM Frequency A091
Auto Rstrt Tries A092
Auto Rstrt Delay A093
Start At PowerUp A094
Reverse Disable A095
Flying Start En A096
Compensation A097
SW Current Trip A098
Process Factor A099
Fault Clear A100
Program Lock A101
Testpoint Sel A1 0 2
Comm Data Rate A103
Comm Node Addr A104
Comm Loss Action A105
