Rockwell Automation Publication 1783-UM007G-EN-P - February 2017 215
Configure Switch Features Chapter 7
DLR Port Choices
Table 41 and Table 42 show which ports you can configure for DLR:
• Stratix 5700 and ArmorStratix 5700 switches support one ring and two
DLR-enabled ports per switch.
• Stratix 5400 switches support as many as three rings and six
DLR-enabled ports per switch.
We recommend that you use the Multiport Automation Device Smartport role
on ports you configure for DLR.
Table 41 - DLR Port Choices for Stratix 5400 Switches
Ring 1 Ring 2 Ring 3
Switch Port 1 Port 2 Port 1 Port 2 Port 1 Port 2
1783-HMS4C4CGN 1, 5 2, 6 3, 7 4, 8 7 8
1783-HMS8T4CGN 1, 5 2, 6 3, 7 4, 8 9 10
1783-HMS8S4CGN 1, 5 2, 6 3, 7 4, 8 9 10
1783-HMS4T4E4CGN 1, 9 2, 10 3, 11 4, 12 7 8
1783-HMS16T4CGN 1, 5 2, 6 3, 7 4, 8 9 10
1783-HMS4S8E4CGN 1, 5, 9 2, 6, 10 3, 7, 11 4, 8, 12 1, 7, 13 2, 8, 14
1783-HMS8TG4CGN 1, 5 2, 6 3, 7 4, 8 9 10
1783-HMS8TG4CGR
1783-HMS8SG4CGN 1, 5 2, 6 3, 7 4, 8 9 10
1783-HMS8SG4CGR
1783-HMS4EG8CGN 1, 5, 9 2, 6, 10 3, 7, 11 4, 8, 12 1, 7, 9 2, 8,10
1783-HMS4EG8CGR
1783-HMS16TG4CGN 1, 5 2, 6 3, 7 4, 8 9 10
1783-HMS16TG4CGR
1783-HMS8TG8EG4CGN 1, 5 2, 6 3, 7 4, 8 9 10
1783-HMS8TG8EG4CGR
1783-HMS4SG8EG4CGN 1, 5, 9 2, 6, 10 3, 7, 11 4, 8, 12 1, 7, 13 2, 8, 14
1783-HMS4SG8EG4CGR
