Chapter 1 About the Switches
Hardware Features
See the following for a description of hardware features:
• For Stratix 5400, Stratix 5700, ArmorStratix 5700, and Stratix 8000/
8300 switches, see
Table 3 on page 23.
• For Stratix 5410 switches, see
Table 4 on page 24.
• For supported SFP modules, see the Stratix Ethernet Device
Specifications Technical Data, publication
1783-TD001.
Network Address Translation (NAT) All Stratix 5400 switches
All Stratix 5410 switches
Stratix 5700 switches: 1783-BMS10CGN, 1783-BMS20CGN, 1783-BMS12T4E2CGNK
ArmorStratix 5700 switches: 1783-ZMS4T4E2TGN, 1783-ZMS8T8E2TGN
••
Network Time Protocol Stratix 5400 switches
Stratix 5410 switches
Stratix 5700 switches
ArmorStratix 5700 switches
Stratix 8000 switches
Stratix 8300 switches
• —
Parallel Redundancy Protocol (PRP) Stratix 5400 switches
Stratix 5410 switches
• —
Port Mirroring All
• —
Port Security All
••
Port Thresholds All
••
Power over Ethernet (PoE) Stratix 5400 switches: 1783-HMS4T4E4CGN, 1783-HMS4S8E4CGN, 1783-HMS4EG8CGN,
1783-HMS8TG8EG4CGN, 1783-HMS4SG8EG4CGN,1783-HMS4EG8CGR,
1783-HMS8TG8EG4CGR, 1783-HMS4SG8EG4CGR
All Stratix 5410 switches
Stratix 5700 switches: 1783-BMS12T4E2CGNK, 1783-BMS12T4E2CGP, 1783-BMS12T4E2CGL
ArmorStratix 5700 switches: 1783-ZMS4T4E2TGP, 1783-ZMS8T8E2TGP, 1783-ZMS4T4E2TGN,
1783-ZMS8T8E2TGN
Stratix 8000 and 8300 expansion modules: 1783-MX04E, 1783-MX04T04E
••
Resilient Ethernet Protocol (REP) All
• —
Static and Connected Routing All
• —
Open Shortest Path First (OSPF)
Gateway Routing Protocol
Stratix 5400 switches with Layer 3 firmware
Stratix 5410 switches with Layer 3 firmware
Stratix 8300 base units
• —
Simple Network Management Protocol
(SNMP)
All
• —
Smartports All
••
Spanning Tree Protocol (STP) All
••
Virtual Local Area Networks (VLANs) All
••
Table 2 - Software Features (continued)
Feature Switches Device Manager Logix Designer
