Cables and Connectors Appendix D
The following table lists the pinouts for the console port, the RJ45-to-DB-9
adapter cable, and the console device.
The following table lists the pinouts for the console port, RJ45-to-DB-25
female DTE adapter, and the console device. The RJ45-to-DB-25 female DTE
adapter is not supplied with the switch.
Table 171 - Pinouts with DB-9 Pin
Switch Console Port (DTE) RJ45-to-DB-9 Terminal Adapter Console Device
Signal DB-9 Pin Signal
RTS 8 CTS
DTR 6 DSR
TxD 2 RxD
GND 5 GND
GND 5 GND
RxD 3 TxD
DSR 4 DTR
CTS 7 RTS
Table 172 - Pinouts with DB-25 Pin
Switch Console Port (DTE) RJ45-to-DB-25 Terminal Adapter Console Device
Signal DB-25 Pin Signal
RTS 5 CTS
DTR 6 DSR
TxD 3 RxD
GND 7 GND
GND 7 GND
RxD 2 TxD
DSR 20 DTR
CTS 4 RTS
