Rockwell Automation Publication 1783-UM001B-EN-P - May 2010 33
Network Services Setup Chapter 2
This table shows possible codes that could be in this destination element.
Table 3 - Error Codes
Error Code (hex) Extended-error
Code (hex)
Description
0x00 None Delivery successful to the mail relay server.
0x02 Resource unavailable. The email object was unable
to obtain memory resources to initiate the SMTP
session.
0x08 Unsupported Service Request.
Make sure the service code is 0x4B and the class is
0x32F.
0x11 Reply data too large. The Destination string must
reserve space for the SMTP server reply message.
The reply can be 470 bytes max.
0x13 Configuration data size too short. The Source
Length is less than the Source Element string size
plus the 4-byte length.
The Source Length must equal the Source Element
string size + 4.
0x15 Configuration data size too large. The Source
Length is greater than the Source Element string
size plus the 4-byte length.
The Source Length must equal the Source Element
string size + 4.
0x19 Data write failure.
An error occurred when attempting to write the
SMTP server address (attribute 4) to nonvolatile
memory.
0xFF 0x0100 Error returned by email server; check the
Destination string for reason. The email message
was not queued for delivery.
0x0101 SMTP mail server not configured. Attribute 5 was
not set with a SMTP server address.
0x0102 To: address not specified.
Attribute 1 was not set with a To: address with no
To: field header in the email body.
0x0103 0x0103 From: address not specified. Attribute 2
was not set with a From: address and no From:
field header in the email body.
