AT-2711 Series Fast Ethernet Adapter Installation Guide
89
Jumbo Mtu
The Jumbo Mtu (Maximum transmission unit) feature allows you to specify
the size of the Ethernet frame that the adapter supports. The network
performance usually improves when the larger frame size is specified:
however, the network must be capable of supporting the oversized
Ethernet frames.
To change the Jumbo Mtu setting, do the following:
1. Access the Advanced Properties.
See “Accessing Advanced Properties” on page 76.
2. Select Jumbo Mtu in the Property box.
The Jumbo Mtu page is displayed as shown in Figure 47.
Figure 47. Jumbo Mtu Page
3. Specify the size of the frame in the Value box.
The range of the value is from 1,500 to 9,000. The default value is
1,500.
4. Click OK.
