Modifying Advanced Properties
98
Network Address
The Network Address property allows you to replace the MAC address
originally assigned to the adapter with a user-defined address. The user-
defined address that you assign to the adapter is called a locally
administered address.
The network address overrides the original MAC address stored in
the AT-2711 series adapter card. When you change the MAC
address, ensure that a unique MAC address is assigned.
To assign or change the Network Address, do the following:
1. Access the Advanced Properties.
See “Accessing Advanced Properties” on page 76.
2. Select Network Address in the Property box.
The Network Address page is displayed as shown in Figure 53.
Figure 53. Network Address Page
