Chapter 2: Basic Switch Configuration
42
Delete User Name
and Password
To delete a user name that you have previously added, perform the
following procedure.
1. From the main menu on the left side of the page, click the System
folder.
The System folder expands.
2. From the System folder, select Administration.
The Administration Page is shown in Figure 10 on page 40.
3. Identify the user name that you want to delete and click Delete.
The user name is removed from the Administration table.
Note
The default user name cannot be modified or deleted. The default
password can be modified.
4. From the main menu on the left side of the page, select Save
Configuration to Flash to permanently save your changes.

Table of Contents

Other manuals for Allied Telesis AT-GS950/8

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Allied Telesis AT-GS950/8 and is the answer not in the manual?

Allied Telesis AT-GS950/8 Specifications

General IconGeneral
Ports8 x 10/100/1000BASE-T
Switching Capacity16 Gbps
Forwarding Rate11.9 Mpps
MAC Address Table Size8K
Power SupplyInternal AC power supply
Operating Temperature0°C to 40°C (32°F to 104°F)
Uplink Ports2 x 1000BASE-X SFP
Jumbo Frame Support9K bytes
Dimensions440 x 44 mm
Storage Temperature-40 to 70 °C
Humidity10% to 90% non-condensing
