AT-GS950/8 Web Interface User Guide
105
General Guidelines
Here is a summary of the rules to observe when you create a voice VLAN:
One voice VLAN can be configured on the switch at any time.
A voice VLAN is based on a pre-defined tagged VLAN.
The voice VLAN Auto-Detection feature can only be enabled on
ports that are initially defined as non-members of the tagged
VLAN.
On ports that are configured for the voice VLAN Auto-Detection
feature, each IP phone must be manually configured per the
manufacturer’s instructions for the VLAN ID that matches your
AT-GS950/8 voice VLAN ID.
Member ports of a tagged VLAN are static and cannot have the
voice VLAN Auto-Detection feature enabled.
IP phones that are not VLAN aware should be connected to Static
tagged ports of the voice VLAN.
The voice VLAN uplink/downlink port(s) must be configured as
Static tagged or tagged ports.
Any Static tagged members of the voice VLAN are required to have
the port VLAN ID (PVID) configured to be the same as the voice
VLAN ID.
The Organization Unique Identifier (OUI) is configured by entering
an IP phone’s MAC address into the configuration.
Only one MAC address representing each unique OUI can be
configured at one time.
Up to 10 IP phone MAC addresses/OUIs can be configured at one
time.
Link Layer Discovery Protocol for Media Endpoint Devices (LLDP-
MED) is not supported on the AT-GS950/8 switch.
Power over Ethernet (PoE) is not supported on the AT-GS950/8
switch.
