143
Appendix A
Technical Specifications
This appendix contains the following sections:
 "Physical Specifications”
 "Environmental Specifications” on page 144
 "Power Specifications” on page 144
 "Certifications” on page 145
 "RJ-45 Twisted Pair Port Pinouts” on page 146
 "RJ-45 Style Serial Console Port Pinouts” on page 147
Physical Specifications
Dimensions (H x W x D)
Weights
Ventilation
Table 12. Product Dimensions
AT-XS916MXT 4.3 cm x 21 cm x 32.3 cm
(1.7 in. x 8.3 in. x 12.7 in.)
AT-XS916MXS 4.3 cm x 21 cm x 32.3 cm
(1.7 in. x 8.3 in. x 12.7 in.)
Table 13. Product Weights
AT-XS916MXT 2.8 kg (6.1 lb.)
AT-XS916MXS 2.7 kg (5.9 lb.)
Table 14. Ventilation Requirements
Recommended Minimum
Ventilation on All Sides
10 cm (4.0 in)
