Chapter 6: What to Do First
90
6. Enter the WRITE command to save your change, as shown in
Figure 56.
Figure 56. Saving the Change with the WRITE Command
If this is the initial management session of the switch, the switch
automatically creates in flash memory a new configuration file called
DEFAULT.CFG to store your configuration change. You can change
the name of the file or designate a different file after creating the stack.
7. Restart the switch with the REBOOT command, as shown in
Figure 57.
Figure 57. Rebooting the Switch with the REBOOT Command
8. Type “Y” for yes.
9. Wait two minutes for the switch to initialize its management software.
10. Check the ID LED and do one of the following:
If the ID LED is displaying the number 1 or higher, VCStack is now
enabled on the switch. Power off the switch by disconnecting the
power cord and repeat the procedures in this chapter on the
second switch. Afterwards, go to Chapter 7, “Stacking with the
Default Trunk Ports” on page 91 or Chapter 8, “Stacking with Non-
default Trunk Ports” on page 105.
If the ID LED is still displaying “0,” repeat this procedure. If the
procedure was not successful, it might be because you did not
issue the WRITE command in Step 6 to save your change.
awplus# write
Building configuration ...
[OK]
awplus#
awplus# reboot
reboot system? (y/n):
awplus#
