XS900MX Series Installation Guide for VCStack
71
Installation Guidelines
Here are the guidelines to installing the switch on a wall:
You can install the switch on a wall with wooden studs or a
concrete wall.
If you are installing the switch on a wall with wooden studs, you
should use a plywood base to support the switch. For more
information, refer to “Plywood Base for a Wall with Wooden Studs”
on page 73. A plywood base is not required for a concrete wall.
You should not install the switch on a wall that has metal studs.
Metal studs may not be strong enough to safely support the device.
Do not install the switch on sheetrock or similar material. Sheetrock
is not strong enough to safely support the device.
The device is heavy. Always ask for assistance before moving or
lifting it to avoid injuring yourself or damaging the equipment.
The device should be installed on a wall by a qualified building
contractor. Serious injury to yourself or others or damage to the
equipment may result if it is not properly fastened to the wall.
E105
Tools and
Material
Here are the required tools and material for installing the switch on a wall:
Four AT-BRKT-J24 wall brackets and sixteen screws (included
with the switch)
Cross-head screwdriver (not provided)
Stud finder for a wooden wall, capable of identifying the middle of
wall studs and hot electrical wiring (not provided)
Drill and 1/4” carbide drill bit for a concrete wall (not provided)
Plywood base if you are installing the switch on a wall with wooden
studs (not provided.) Refer to “Plywood Base for a Wall with
Wooden Studs” on page 73 for illustrations.
Four screws to attach the plywood base to the wall (not provided)
Four 6mmx4mmx29.6mm anchors (included with the switch)
Four M4x32mm screws to attach the switch to the wall (included
with the switch)
