Allied Telesis XS900MX Series User Manual

17
Chapter 1
Overview
This chapter contains the following sections:
 “Front Panels” on page 18
 “Features” on page 19
 “Management Panel” on page 21
 “100Mbps and 1/10Gbps Twisted Pair Ports” on page 22
 “1Gbps SFP and 10Gbps SFP+ Ports” on page 23
 “15/S1 and 16/S2 Default Trunk Ports” on page 24
 “eco-friendly Button” on page 25
 “LEDs” on page 26
 “USB Port” on page 30
 “Console Port” on page 31
 “Power Supply” on page 32
 “Specifying Ports in the Command Line Interface” on page 33
Note
This guide explains how to install switches in a stack with the Virtual
Chassis Stacking (VCStack
™) feature. For instructions on how to
install the devices as stand-alone switches, refer to the XS900MX
Series Installation Guide for Stand-alone Switches.

Allied Telesis XS900MX Series Specifications

General

VLANs	4094
Humidity	5% to 95% non-condensing
Model	Allied Telesis XS900MX Series
Layer	Layer 3
Jumbo Frame	9216 bytes
Dimensions	440 mm x 44 mm
Management	Web, CLI, SNMP
Operating Temperature	0°C
