Allied NeXGen User Manual

NeXGen  Wayne Direct - Gilbarco / Installation and Start Up Guide
Copyright  2019 by Allied Electronics, Inc.
December 31, 2019 Page
2-5
2.3.2 Wayne Dispenser Communication
A total of 32 fueling positions may be connected to the controller. Up to 16 may be
connected to channel 5 and up to 16 may be connected to channel 6. Channels 5, 6
and/ or 7 must have a 2-wire custom cable or RJ45 adapter set that will be connected
to the Gilbarco Universal “D” box.
2.3.2.1 Wayne Direct to the Gilbarco Distribution Box
Note: When connecting to the Gilbarco “D” box the dispenser brand (in the Station
wide configuration options) must be set to a lower case”d”
NeXGen (CH5, CH6 or CH7) RJ45 adapter to Wayne Direct via the Gilbarco “D” box (DB9)
(Part #N9323W-ADP)
NeXGen
RJ45
Pins
CAT 5 Cable
(T568B Spec.)
RJ45
Mod Jack
Pins
Gilbarco “D box
DB9 Female
Pins
-
6
-----------
Green
-------------
6 (Yel)
6
-
+ 7
-----------
Wht/Brn
-------------
7 (Brn)
7 +
NeXGen (CH5, CH6 or CH7) RJ45 adapter to Wayne Direct via the Gilbarco “D” box (RJ45)
NeXGen
RJ45
Pins
CAT 5 Cable
(T568B Spec.)
Gilbarco “D box
DB9 Female
Pins
-
6
-----------
Green
-------------
6
-
+ 7
-----------
Wht/Brn
-------------
7 +
