NeXGen Wayne Direct - Gilbarco / Installation and Start Up Guide
Copyright 2019 by Allied Electronics, Inc.
December 31, 2019 Page
3-11
3.2.4 Gilbarco Blending Dispensers
Gilbarco Variable Blenders
The NeXGen interfaces to the following Gilbarco variable blenders:
3+0 4+0 5+0
3+1 4+1 5+1
A variable blender without diesel, or 3+0, will have position 1, grade 1 on the left on both sides
of the pump. Gilbarco products are mapped as positions 1, 3 and 5 (Advantage) and positions
1, 2 and 3 (Advantage with “Optimized” electronics), Low grade, Mid grade and High grade
respectively, from left to right when facing each side of the dispenser. A 5+0 will have the
products mapped as positions 1, 2, 3, 4 and 5. Low grade, blend grade 1, blend grade 2, blend
grade 3 and High grade. The following is an example of a 3+0.
An advantage variable blender with diesel, or 3 + 1, will always have the diesel product for
each side mirrored with one another. The diesel will be on the right when facing side A, while
diesel will be on the left when facing side B. Gilbarco maps the diesel product as product 6.
The remaining grades are mapped the same as the 3 + 0 described above. The pump is
shown below:
B side
product 3
position 5
position 3
product 2
position 3
position 2
product 1
position 1
position 1
Advantage
Adv. w/ optimized & Encore
A side
product 1
position 1
position 1
product 2
position 3
position 2
product 3
position 5
position 3
Advantage
Adv. w/ optimized & Encore
B Side
product 3
position 5
position 3
product 2
position 3
position 2
product 1
position 1
position 1
product 4
position 6
position 6
Advantage
Adv. w/ optimized & Encore
A Side
product 1
position 1
position 1
product 2
position 3
position 2
product 3
position 5
position 3
product 4
position 6
position 6
Advantage
Adv. w/ optimized & Encore
