Allied NeXGen User Manual

NeXGen  Wayne Direct - Gilbarco / Installation and Start Up Guide
Copyright  2019 by Allied Electronics, Inc.
December 31, 2019 Page
3-9
3.2.2 Gilbarco Distribution Box Jumper Settings
The NeXGen controller communicates with the Gilbarco dispensers and CRINDs via
two wire communications and uses 45mA current loop ports.
Channel 5 and Channel 6 on the NeXGen can each communicate with up to sixteen
fueling positions. Channel 7 can communicate with up to 32 CRINDs.
The following is a list of the jumper settings for the Gilbarco distribution box for both
pump and CRIND communications.
Two wire configuration (45ma)
Jumper
Jumper setting for Boards 1 and 2
JP10 Horizontal
JP12 Horizontal
JP9 Horizontal (Pumps/CRINDs/IPTs)
JP14 Installed
Single and dual board configurations (There are three options:)
 1 board, 1 input
o 8 loops for dispensers or CRINDS on board 1
 2 boards, 1 input
o 16 loops for dispensers or CRINDs on boards 1 & 2
 2 boards, 2 inputs
o 8 loops for dispensers on board 1 and 8 loops for CRINDs on board 2
OR
o 8 loops for dispensers on board 1 and 8 loops for dispensers on board 2.
Option
Jumper setting for Board 1
Jumper setting for Board 2
1 JP11, set to “B” N/A
1 JP13, set to “B” N/A
2 JP11, set to “B” JP11, set to “A”
2 JP13, set to “A” JP13, set to “B”
3 JP11, set to “B” JP11, set to “B”
3 JP13, set to “B” JP13, set to “B”
