NeXGen Wayne Direct - Gilbarco / Installation and Start Up Guide
Copyright 2019 by Allied Electronics, Inc.
December 31, 2019 Page
1-4
1.6 Overview
The NeXGen controller interfaces to the following devices:
Wayne Dispensers & CATs
1. Wayne dispensers via the 20/30/45 mA current loop & RS485 4-port board, which
is connected to the manufacturer’s distribution box or appropriate 3
rd
party
distribution box.
2. Wayne CATs, Graphic displays, Debit MSM modules and Cash acceptors via a 4
channel RS-485 interface board which can be connected to the Allied Isolation box
or can be hard wired directly to the individual CATs via a junction box.
3. DSM (DUKPT Security Module) or MSM (Security Module) for CAT systems with
debit support. The controller communicates to the unit via the RS485 port used for
CAT communications.
Gilbarco Dispensers & CRINDs
1. Gilbarco dispensers via the 20/30/45 mA current loop & RS485 4-port board, which
is connected to the manufacturer’s Universal Distribution Box.
Point - Of - Sale (POS)
1. Generic PC based Point -Of -Sale Computer via an RS-232 port or Ethernet port,
supporting the ANDI protocol interface.
OPW OPT
1. OPW OPT via an RS485 port. Software Version 18.01A, or newer, must be installed in
the OPT.
Tank gauge
1. Veeder-Root TLS 250, 350 & 350R or equivalent tank gauge system via an RS-
232 port.
2. Any Tank Gauge system that supports the Veeder Root protocol.
Car Wash
1. Ryko III, Ryko IV, Unitec POS 4000, Unitec/Enterlink, Unitec Portal Ti, Unitec Smart
Terminal, PDQ, Kesseltronics and Exacta Car Wash controllers via a fully populated
RS-232 board.
2. Ryko compatible controllers
