3.2.3 Gilbarco Dispenser & CRIND Addressing
3.2.3.1 Gilbarco Dispenser & CRIND Addressing
Channel 6 has been designated to communicate with the Gilbarco dispensers. This channel can
accommodate up to 16 fueling positions. The address of the first fueling position will be set to address “1”,
the second to address “2” etc.
The NeXGen controller uses Channel 7 to communicate with the Gilbarco CRINDS. The CRIND device
address must be one less than the fueling position number.
Fueling Position
CRI
ND Address
Fueling
Position
Address NeXGen
Channel
Advantage/
E300
Encore
500
NeXGen
Channel
1 1 CH-6 0 (no JMP) 32 CH-7
2 2 CH-6 1 1 CH-7
3 3 CH-6 2 2 CH-7
4 4 CH-6 3 3 CH-7
5 5 CH-6 4 4 CH-7
6 6 CH-6 5 5 CH-7
7 7 CH-6 6 6 CH-7
8 8 CH-6 7 7 CH-7
9 9 CH-6 8 8 CH-7
10 10 CH-6 9 9 CH-7
11 11 CH-6 10 10 CH-7
12 12 CH-6 11 11 CH-7
13 13 CH-6 12 12 CH-7
14 14 CH-6 13 13 CH-7
15 15 CH-6 14 14 CH-7
16 16 CH-6 15 15 CH-7
