Allied NeXGen User Manual

NeXGen  Wayne Direct - Gilbarco / Installation and Start Up Guide
Copyright  2019 by Allied Electronics, Inc.
December 31, 2019 Page
2-9
2.3.6 Tank Gauge Communication
The NeXGen uses Channel 2 to interface to a Veeder-Root or equivalent tank gauge
system. Configure the tank gauge communication parameters as follows:
Baud Rate: 9600 Parity: Odd Stop Bits: 1 Data Bits: 7
2.3.6.1 Veeder Root TLS 250/350
On a TLS-250, the communication parameters are set using a rotary switch and DIP
switches, (please refer to the TLS 250 manual).
On a TLS-350, the communication parameters are programmed via the TLS keyboard
(please refer to the TLS 350/350R manual).
On a TLS-450, the communication parameters are programmed via the
touch-screen display (please refer to the TLS 450 manual).
NeXGen (CH 2) RJ45 adapter to the VR TLS 250/350
(Part #N9338-ADP)
NeXGen
RJ45
Pins
CAT 5 Cable
(T568B Spec.)
RJ45
Adapter
Pins
TLS
DB25 Male
Pins
RXD 3
--------------
Wht/Grn
--------------
3 (Blk)
2 TXD
TXD 5
--------------
Wht/Blu
--------------
5 (Grn)
3 RXD
GND 8
--------------
Brown
--------------
8 (Wht)
7 GND
2.3.6.2 Veeder Root TLS 450
NeXGen (CH2) RJ45 adapter to the VR TLS 450
(Part #N9445-ADP)
NeXGen
RJ45
Pins
CAT 5 Cable
(T568B Spec.)
RJ45
Modular Jack
Pins
TLS
DB9 Male
Pins
DSR 2
--------------
Orange
--------------
2 (Org)
4 DTR
RXD 3
--------------
Wht/Grn
--------------
3 (Blk)
3
TXD
RTS 4
--------------
Blue
--------------
4 (Red)
8 CTS
TXD 5
--------------
Wht/Blu
--------------
5 (Grn)
2 RXD
CTS 6
--------------
Green
--------------
6 (Yel)
7 RTS
DTR 7
--------------
Wht/Brn
--------------
7 (Brn)
6 DSR
GND 8
--------------
Brown
--------------
8 (Wht)
5 GND
