Allied NeXGen User Manual

NeXGen  Wayne Direct - Gilbarco / Installation and Start Up Guide
Copyright  2019 by Allied Electronics, Inc.
December 31, 2019 Page
3-1
3 Programming
3.1 Wayne Direct Addressing
3.1.1 Wayne Direct Dispensers, CATs and OPT
Channel 5 has been designated to communicate to the Wayne dispensers (a maximum of 16 fueling positions).
The address of the first fueling position on Channel 5 will be set to address “1”, the second to address “2” etc.
Note: Up to 16 CATs may be connected to the NeXGen on channel 8. For Master Key/ Session Key debit , the
MSM responds to poll address 30, limiting the number of CATs to 29.
The NeXGen controller uses channel 12 to communicate with the OPW OPT. Up to 16 OPT’s can be supported
and software Version 18.01A, or newer, must be installed. The OPT uses decimal address 32 – 47.
Fueling Position
CAT
OPT
Fueling Point Address
NXG
Channel
Address
NeXGen
Channel
OPT
NeXGen
Channel
1 1 CH-5 1 CH-8 32 CH-12
2 2 CH-5 2 CH-8 33 CH-12
3 3 CH-5 3 CH-8 34 CH-12
4 4 CH-5 4 CH-8 35 CH-12
5 5 CH-5 5 CH-8 36 CH-12
6 6 CH-5 6 CH-8 37 CH-12
7 7 CH-5 7 CH-8 38 CH-12
8 8 CH-5 8 CH-8 39 CH-12
9 9 CH-5 9 CH-8 40 CH-12
10 10 CH-5 10 CH-8 41 CH-12
11 11 CH-5 11 CH-8 42 CH-12
12 12 CH-5 12 CH-8 43 CH-12
13 13 CH-5 13 CH-8 44 CH-12
14 14 CH-5 14 CH-8 45 CH-12
15 15 CH-5 15 CH-8 46 CH-12
16 16 CH-5 16 CH-8 47 CH-12
