Table 6: Wiring Connections HV-ADIO (Sheet 1 of 2)
Terminal Description Signal Type Range
Power Connections
1, 2, and 3; PWR Power Input GND / Neg (-) / Pos (+) 90 to 300Vdc
16 and 17 Power Output Neg (-) / Pos (+) 25 to 55VDC 0.7A Max
Analog Inputs
26 and 27; T1 Temperature 1 Pos (+) / Neg (-) -40C to 85C with Alpha
Temp sensor
28 and 29; T2 Temperature 2 Pos (+) / Neg (-) -40C to 85C with Alpha
Temp sensor
30-33; DCCT1 DCCT1 4pin Hall Sensor -10V to +10V
34-37; DCCT2 DCCT2 4pin Hall Sensor -10V to +10V
38 and 39; V1 Voltage 1 Pos (+) / Neg (-) -300 to +300Vdc
40 and 41; V2 Voltage 2 Pos (+) / Neg (-) -300 to +300Vdc
42 and 43; I1 Current 1 Pos (+) / Neg (-) ±25, ±50, ±100mV,
±200mV
Relay Outputs
4, 5 and 6; K1 Relay 1 NC / COM / NO 300Vdc / 50W MAX
7, 8 and 9; K2 Relay 2 NC / COM / NO 300Vdc / 50W MAX
10, 11 and 12; K3 Relay 3 NC / COM / NO 300Vdc / 50W MAX
13, 14 and 15; K4 Relay 4 NC / COM / NO 300Vdc / 50W MAX
44, 45 and 46; K5 Relay 5 NC / COM / NO 300Vdc / 50W MAX
47, 48 and 49; K6 Relay 6 NC / COM / NO 300Vdc / 50W MAX
Digital Inputs
24 and 25; D1 Digital Input 1 Contact closure detect Open or Short
26 and 27; D2 Digital Input 2 Contact closure detect Open or Short
28 and 29; D3 Digital Input 3 Contact closure detect Open or Short
To Next Page
