2. General Description
2.1 Overview
The Alpha FXM is available in 3 models – FXM 650, FXM 1100 and FXM 2000. The FXM 650 and the FXM
1100/2000 look different, but all of the front panel connectors and circuit breakers operate in the same way. How-
ever the circuit breakers for each unit have different ratings. See “Specifications” for details. All units operate in
the same way unless stated otherwise in this manual.
• FXM 650-24VDC – with a 24 VDC battery string voltage.
• FXM 650-48VDC – with a 48 VDC battery string voltage.
• FXM 1100-48VDC – with a 48 VDC battery string voltage.
• FXM 2000-48VDC – with a 48 VDC battery string voltage.
2.2 Front Panel.
)LJXUH ² );0IURQWSDQHOGHVFULSWLRQ
)LJXUH ² );0IURQWSDQHOGHVFULSWLRQ
