Packaging -- Shipping and storage
Packaging -- Identification -- Storage
L22--008EN/01
3/4
09--2003
E ALSTOM
Identifying sub--assemblies an d th eir p ackag in g
Introduction
Each circuit--breaker sub--assembly (poles, operating mechanism, etc.) is
identified by a plate giving its reference numbers.
These numbers are marked on the packaging cases of each sub--assembly.
Example of marking
and identifying
-- Manufacturer reference No. = 101 525
-- Circuit--breaker identification No. 1
-- Pole No. 2
101 525 0010
n
o
SÉRIE
Rep. 01/2
101 525 0010
MANUFACTURER
REFERENCE No.
POLE No.
MARKING OF
PACKAGING CASES
IDENTIFICATION OF SUB--
ASSEMBLIES AND TOOLING
1
2
0101
CIRCUIT--BREAKER
IDENTIFICATION No.
CASE No.
Place of the plates
Choose and install the components identified by the plate (1) and self--
adhesive (3).
101 525 0010
n
o
SÉRIE
Rep. 01/2
OUTSIDE PLATE
INSIDE PLATE
1
3
