Alstom GL314 - Page 64

Installation
Support--frame assembly
L31--113EN/01
6/6
06--2003
E ALSTOM
Frame--support assembly, continued
Process, continued
The table below gives the steps of installing the supports of the frame :
Step Action
3
Position the last frame--supports (2) onto the housing (10) andfasten
with the use of the screws (7).
2
10
2
x2
H M16--35
18 daN.m
7
x2
H M16--35
18 daN.m
7
