Altivar Process ATV650 - Page 26

26 EAV64301 01/2015
Frame size 3
IP21 / UL Type 1 Drives - Front and Side View
Drives without IP21 top cover - Side and Rear View
Weights
Catalog Number Weight in kg (lb)
ATV630U75M3 7.7 (17)
ATV630D11M3 13.8 (30.4)
ATV630D15N4 13.6 (30)
ATV630D18N4 14.2 (31.3)
ATV630D22N4 14.3 (31.5)
