Altivar Process ATV650 - Page 27

EAV64301 01/2015 27
Frame size 4
IP21 / UL Type 1 Drives - Side, Front and Rear View
Drives IP21 without top cover - Side and Rear View
Weights
Catalog Number Weight in kg (lb)
ATV630D15M3...D22M3 27.3 (60.2)
ATV630D30N4 28 (61.7)
ATV630D37N4 28.2 (62.2)
ATV630D45N4 28.7 (63.3)
