44 EAV64301 01/2015
IP21 / UL Type 1 Products 3-Phase Power Part Supply 380…480 Vac 50/60 Hz
Catalog Number and
Frame Size (S•)
Nominal Power
(1)
Power Part Supply Drive (output)
Max. Input Current Apparent
Power
Max.
Inrush
Current
(2)
Nominal
Current (1)
Max.
Transient
current (1)
(3)
At
380 Vac
At
480 Vac
kW HP A A kVA A A A
ATV630U07N4 S1 0.37 1/2 0.9 0.8 0.7 8 1.5 2.3
ATV630U15N4 S1 0.75 1 1.7 1.5 1.2 8.3 2.2 3.3
ATV630U22N4 S1 1.5 2 3.1 2.9 2.4 8.4 4 6
ATV630U30N4 S1 2.2 3 4.5 4.0 3.3 31.5 5.6 8.4
ATV630U40N4 S1 3 - 6.0 5.4 4.5 32.2 7.2 10.8
ATV630U55N4 S1 4 5 8 7.2 6.0 33.2 9.3 14
ATV630U75N4 S2 5.5
7
1/2
10.5 9.2 7.6 39.9 12.7 19.1
ATV630D11N4 S2 7.5 10 14.1 12.5 10.4 40.4 16.5 24.8
ATV630D15N4 S3 11 15 20.6 18.1 15 74.5 23.5 35.3
ATV630D18N4 S3 15 20 27.7 24.4 20.3 75.5 31.7 47.6
ATV630D22N4 S3 18.5 25 34.1 29.9 24.9 76 39.2 58.8
ATV630D30N4 S4 22 30 40.5 35.8 29.8 83 46.3 69.5
ATV630D37N4 S4 30 40 54.8 48.3 40.2 92 61.5 92.3
ATV630D45N4 S4 37 50 67.1 59 49.1 110 74.5 111.8
ATV630D55N4 S5 45 60 81.4 71.8 59.7 176 88 132
ATV630D75N4 S5 55 75 98.9 86.9 72.2 187 106 159
ATV630D90N4 S5 75 100 134.3 118.1 98.2 236 145 217.5
ATV630C11N4 S6 90 125 170 143 102.6 325 173 259.5
ATV630C13N4 S6 110 150 201 165 121.8 325 180 270
ATV630C16N4 S6 132 200 237 213 161.4 325 240 360
(1) The switching frequency is adjustable:
z From 1...16 kHz for drive frame sizes 1 to 4, rated value: 4 kHz
z From 1...8 kHz for drive frame sizes 5 and 6, rated value: 2.5 kHz
For operation at switching frequencies higher than the rated value. Derating must be applied to the drive (output)
current (see page 46). In this case, switching frequency can be reduced if an excessive temperature rise occurs.
(2) Peak current when power is switched On, for the maximum supply mains voltage.
(3) The drive is designed to run up to 60 s at 150% of nominal current.
(4) First value is the power dissipated at nominal current in a forced cooled area. The second value in italic is the power
dissipated at nominal current in a natural cooled area, value used in case of installation using the flush-mounting
kit, separate hot and cold part in a cabinet.
