EAV64301 01/2015 45
IP55 Products 3-Phase Power Part Supply 380…480 Vac 50/60 Hz
Catalog Number and
Frame Size (S•)
Nominal
Power (1)
Power Part Supply Drive (output)
Max. Input Current Apparent
Power
Max.
Inrush
Current
(2)
Nominal
current (1)
Max.
transient
current (1)
(3)
At
380 Vac
At
480 Vac
kW HP A A kVA A A A
ATV650U07N4 SA 0.37 1/2 0.9 0.8 0.7 8.0 1.5 2.3
ATV650U15N4 SA 0.75 1 1.7 1.5 1.2 8.3 2.2 3.3
ATV650U22N4 SA 1.5 2 3.1 2.9 2.4 8.4 4 6
ATV650U30N4 SA 2.2 3 4.5 4.0 3.3 31.5 5.6 8.4
ATV650U40N4 SA 3 - 6 5.4 4.5 32.2 7.2 10.8
ATV650U55N4 SA 4 5 8 7.2 6.0 33.2 9.3 14
ATV650U75N4 SA 5.5
7
1/2
10.5 9.2 7.6 39.9 12.7 19.1
ATV650D11N4 SA 7.5 10 14.1 12.5 10.4 40.4 16.5 24.8
ATV650D15N4 SA 11 15 20.6 18.1 15 74.5 23.5 35.3
ATV650D18N4 SA 15 20 27.7 24.4 20.3 75.5 31.7 47.6
ATV650D22N4 SA 18.5 25 34.1 29.9 24.9 76 39.2 58.8
ATV650D30N4 SB 22 30 40.5 35.8 29.8 83 46.3 69.5
ATV650D37N4 SB 30 40 54.8 48.3 40.2 92 61.5 92.3
ATV650D45N4 SB 37 50 67.1 59 49.1 109.7 74.5 111.8
ATV650D55N4 SC 45 60 81.4 71.8 59.7 176 88 132
ATV650D75N4 SC 55 75 98.9 86.9 72.2 187 106 159
ATV650D90N4 SC 75 100 134.3 118.1 98.2 236 145 217.5
(1) The switching frequency is adjustable:
z From 1...16 kHz for drive frame sizes A and B, rated value: 4 kHz
z From 1...8 kHz for drive frame size C, rated value: 2.5 kHz
For operation at switching frequencies higher than the rated value. Derating must be applied to the drive (output)
current (see page 46). In this case, switching frequency can be reduced if an excessive temperature rise occurs.
(2) Peak current when power is switched On, for the maximum supply mains voltage.
(3) The drive is designed to run up to 60 s at 150% of nominal current.
(4) First value is the power dissipated at nominal current in a forced cooled area. The second value in italic is the power
dissipated at nominal current in a natural cooled area, value used in case of installation using the flush-mounting
kit, separate hot and cold part in a cabinet.
