COMBITHERM INSTALLATION AND MAINTENANCE MANUAL #6004/18
PG. 25
MECHANICAL PARTS
Drain Screen DA-2943 DA-2943 DA-2943
Fan Wheel WH-3734 WH-3734 WH-3734
Leg LG-23907 LG-23907 FE-23822
Oven Light Bulb LP-3686 LP-3686 LP-3686
Oven Light Glass Cover LP-33413 LP-33413 LP-33413
Oven Light Receptacle RP-3986 RP-3986 RP-3986
Oven Light Cover CV-23896 CV-23896 CV-23896
Oven Light Cover Seal SA-23933 SA-23933 SA-23933
Oven Light Cover Mounting Screws (4) SC-22281 SC-22281 SC-22281
Oven Light O-Ring SA-23934 SA-23934 SA-23934
Product Probe PR-33286 PR-33286 PR-33286
DOOR PARTS
Door Drip Tray External 4198 4198 —
Door, Gasket GS-23903 GS-22694 GS-2954
Door, Glass Assembly 15589 15792 15318
Door Handle HD-2934 HD-2934 HD-2934
Door Hinge Set HG-22192 HG-22192 HG-22850
Door Latch LT-2935 LT-2935 LT-2935
Door Latch, Interlock Switch (INSIDE LATCH) LT-3738 LT-3738 LT-3738
Door Latch Spacer SP-23941 SP-23941 SP-23941
Door Magnet, Permanent Solenoid MA-3739 MA-3739 MA-3739
WATER / PLUMBING PARTS
Decalcification Cap CP-23895 CP-23895 CP-23895
Decalcification Cap Seal WS-22752 WS-22752 WS-22752
Double Solenoid Valve Assembly VA-3820 VA-3820 VA-3820
Double Solenoid Valve Body VA-2926 VA-2926 VA-2926
Double Solenoid Valve Coil VA-3681 VA-3681 VA-3681
Hand Held Shower Assembly 14442 14168 14577
includes:
— Hand Shower Sprayer PB-23919 PB-23919 PB-23919
— Hand Shower Handle PB-23920 PB-23920 PB-23920
— Hand Shower Hose PB-23922 PB-24066 PB-24066
Hand Shower Holder PB-23921 PB-23921 PB-23921
MISCELLANEOUS PARTS
Gasket, Control Panel GS-23622 GS-23622 GS-23622
Roll-In Cart, Stainless Steel ——5815
Shelf, Stainless Steel SH-22584 SH-22584 SH-22473
Side Rack, Left-Hand 14458 14745 —
Side Rack, Right-Hand 14459 14746 —
Side Rack Stop SR-23942 SR-22745 —
COMBITHERM REPLACEMENT PARTS
Description 7•14 10•18EC 20•20EC
COMBITHERM® SERVICE and TROUBLE SHOOTING
PRIOR TO STARTING SERVICE WORK, THE OVEN MUST BE DISCONNECTED FROM THE POWER SOURCE.
