COMBITHERM INSTALLATION AND MAINTENANCE MANUAL #6004/18
PG. 7
COMBITHERM® INSTALLATION and SPECIFICATIONS
Description 7•14 10•18 20•20
Chicken Roasting Rack
— 6 chicken capacity
(fits on full-size pan) SH-23000 SH-23000 SH-23000
— 8 chicken capacity
(fits on full-size pan) SH-23619 SH-23619 SH-23619
— 10 chicken capacity SH-22634 SH-22634 SH-22634
Grease Tray Package
(for use with roasting racks)
— 1-1/2" (57mm) deep 4758 4758 4758
— 2-3/4" (70mm) deep 14475 14475 14475
Leg Extension Assembly
(for counter-top placement) 15594 15594 N/A
Oven Cleaner CE-24750 CE-24750 CE-24750
Specially formulated for Combitherm Ovens
Twelve (12) containers/case, 1 quart. (c. 1 liter) each
Oven Stand
(wxdxh) 34-5/8" x 27-3/16" x 27-3/4"
(880mm x 690mm x 705mm)
— With Pan Shelf only 14342 14342 —
— With Pan Slides and Shelf 14343 14343 —
— Mobile With Pan Shelf only 14544 14544 —
— Mobile With Pan Slides and Shelf 14545 14545 —
Preheat Sealing Strip
—
For use in place of roll-in cart while preheating ——14568
Rack Management Trolley System
— Pan Rack Assembly 15639 15638 —
— Rack Track Assembly 14582 14582 —
— Base Trolley Assembly 15635 15635 —
Roll-In Cart
—
Interchangeable with 20•20W and QC-100 ——5815
Shelves, Stainless Steel Wire SH-22473 SH-22473 SH-22473
Stacking Hardware Kit
— 6•10 over 7•14 15813
— 7•14 over 7•14 15420
— 6•10 over 10•18 15835
Ventless Hood
(factory installation only) 15673 15681 —
Water Conditioner Kit
(includes 1 filter cartridge) FI-23014 FI-23014 FI-23014
Water Conditioner Cartridge
(1 filter cartridge) FI-23017 FI-23017 FI-23017
Safety and Operational
Precautions:
●
Before opening the oven door during normal operation, always press
the STOP key and wait a few seconds to allow the fan to stop rotating.
●
Before using the hand sprayer, wait until the cooking compartment
has cooled down to at least 130°F (54°C).
●
When using the hand sprayer, make certain the power switch is in the
OFF position.
●
Never use the oven cleaner or the hand sprayer to clean the outer
surface of the oven.
●
Flush the steam generator on a daily basis, clean the oven and oven
gasket on a daily basis.
●
To avoid unneccessary heat loss and the possibility of overheating the
convection heating elements,
NEVER preheat the model 20•20
without a roll-in cart (trolley) or a preheat sealing strip.
NEVER allow this model to remain in te stand-by mode for prolonged
periods
without a roll-in cart (trolley) or a preheat sealing strip.
Options and Accessories
Steam!!
For safe release of the cooking
compartment steam, initially open
the door approximately 2" (50mm)
only. Stand behind the door as
the hot steam is released.
