COMBITHERM INSTALLATION AND MAINTENANCE MANUAL #6004/18
PG. 5
COMBITHERM® INSTALLATION and SPECIFICATIONS
Model 7•14 10•18 20•20
Installation Data
Type of unit Counter-top Counter-top Floor Standing
Pan capacity 7 Full-size sheet pans* 10 Full-size sheet pans* 20 Full-size sheet pans*
(18" x 26" x 1") (18" x 26" x 1") (18" x 26" x 1")
*Additional wire shelves On wire shelves only On wire shelves only On wire shelves only
required for maximum capacity 14 Full-size pans 20 Full-size pans 40 Full-size pans
(20" x 12" x 2-1/2") (20" x 12" x 2-1/2") (20" x 12" x 2-1/2")
Side Rack spacing 2-5/8" (65mm) 2-5/8" (65mm) 2-5/8"
Net Weight 365 lb (166 kg) 514 lb (233 kg) 958 lb (435 kg)
Electrical specs
208/240V — 60 Hz, 1 ph At 208V At 240V Single Phase Not Available Single Phase Not Available
Power connection 13.9 kW 18.6 kW
Power convection 13.8 kW 18.3 kW
Power Steam 12.2 kW 17.5 kW
Motor Power 0.12 kW 0.3 kW
Current (Amps) 66.2 76.4
Terminal Block connection
2 Wire Plus Ground
AWG 3 or larger
208/240V — 60 Hz, 3 ph At 208V At 240V At 208V At 240V At 208V At 240V
Power connection 13.9 kW 18.6 kW 21.7 kW 28.9 kW 54.3 kW 72.4 kW
Current (Amps/phase) 38.2 44.1 60.3 69.6 150.9 174.4
Terminal Block connection
3 Wire Plus Ground 3 Wire Plus Ground 3 Wire Plus Ground
AWG 6 or larger AWG 2 or larger AWG 4 or larger
440/480V — 50/60 Hz, 3 ph At 440V At 480V At 440V At 480V At 440V At 480V
Power connection 15.3 kW 18.1 kW 30.3 kW 36.0 kW 60.8 kW 72.4 kW
Current (Amps/phase) 20.1 21.8 39.8 43.4 80.0 87.2
Terminal Block connection
3 Wire Plus Ground 3 Wire Plus Ground 3 Wire Plus Ground
AWG 6 or larger AWG 6 or larger AWG2 or larger
Noise Level 44 dB(A) 44 dB(A) 44 dB(A)
Construction Stainless Steel Type 304 Stainless Steel Type 304 Stainless Steel Type 304
Interior 20 gauge Interior 20 gauge Interior 20 gauge,
Exterior 20 gauge Exterior 20 gauge Exterior 20 gauge,
Hose length hand shower 86-5/8" (2200mm) 86-5/8" (2200mm) 86-5/8" (2200mm)
Cold water intake 3/4" NPT 3/4" NPT 3/4" NPT
Water pressure 45 to 75 psi 45 to 75 psi 45 to 75 psi
(3 to 5 bar) (3 to 5 bar) (3 to 5 bar)
Drain connection 1-1/4" NPT 1-1/4" NPT 1-1/4" NPT
